UH230B Undercounter Dishwashing Machine

Spec Sheet File Manual File Revit File Front File Plan File Side File
Model #:
UH230B
Exterior Dimensions:
33-3/4" H x 24" W x 25" D
Recommended Use:
Light Medium Soil - up to 50 seats
Temperature:
High Temp
Capacity per Hour:
30 racks (fast)
Voltage:
208-240
Learn More
Call Us: 905-562-4195
Find a Sales Rep Find Service & Parts

Product Description

STANDARD FEATURES

  • NEW “Shear Energy” – a reduction in energy requirements while maximizing performance!
  • NEW “Multi-Power” – includes “Multi-Volt” and “Multi-Phase”. Allows for infield conversion to 208-240 volt and/or single to three phase with ease.
  • StemSure™ – Soft start to protect glasses and dishes from chipping and breaking
  • Rinse Sentry – extends the cycle time to ensure 180°F final rinse.
  • Built-in electric booster for 180°F/82°C final rinse water (70°F/39°C rise)
  • Pumped drain
  • Low-water tank heat protection
  • Detergent and rinse aid pumps
  • Quiet double-wall construction
  • Door safety switch
  • Independent stainless steel interchangeable upper and lower wash and rinse arms
  • Top mounted slide-out controls
  • Stainless steel top and side panels
  • 90-second total cycle time
  • Extended wash for difficult ware cleaning & de-liming
  • Automatic drain cycle
  • 1 HP motor
  • Advanced Digital Temperature Monitoring
  • Stainless steel construction
  • NSF Certified Pot and Pan Cycle in extended wash cycle
Spec Sheet Manual Cleaning Guide Parts Manual Installation Guide Brochure Revit File Auto CAD Front File Auto CAD Plan File Auto CAD Side File

Limited Warranty: 1 Year Parts & Labour

  • Additional Dish Racks
  • 17" Stand Stainless Steel
  • 8" Stand Stainless Steel
  • 9kW High Speed Rise Booster
  • 3 Phase Connection (prewired at factory)
  • 1" Roller Kit (includes 4 casters)
  • Power Cord Kit
  • NEW Champion ION Scale Prevention System
  • Drain Water Tempering Kit (unmounted)

    • Product Videos

    Custom Field

    Model # UH230B
    Exterior Dimensions 33-3/4" H x 24" W x 25" D
    Recommended Use Light Medium Soil - up to 50 seats
    Temperature High Temp
    Capacity per Hour 30 racks (fast)
    Voltage 208-240
    Resource - PDF - Spec Sheet https://store-txp4k4lqe2.mybigcommerce.com/content/spec-sheets/Undercounters/UH230B.pdf
    Resource - PDF - Manual https://store-txp4k4lqe2.mybigcommerce.com/content/current-production-manuals/Undercounters/Install_Ops_UHM4.2_115440.pdf
    Resource - PDF - Cleaning Guide https://store-txp4k4lqe2.mybigcommerce.com/content/cleaning-operation-guides/Undercounters/Undercounters_CLEANING.pdf
    Resource - PDF - Parts Manual https://store-txp4k4lqe2.mybigcommerce.com/content/current-production-manuals/Undercounters/Parts_UHM4.2_115440.pdf
    Resource - PDF - Installation Guide https://store-txp4k4lqe2.mybigcommerce.com/content/cleaning-operation-guides/Undercounters/Undercounters_INSTALLATION.pdf
    Resource - PDF - Brochure https://store-txp4k4lqe2.mybigcommerce.com/content/brochures/Champion_Powder_Coated_Dishwashers_Brochure_2024.pdf
    Additional Information Limited Warranty: 1 Year Parts & Labour
